Energies 2017,10, 1217 thechargingtimetodistinguish theirvehicles in theEVmarkethasbecomethecurrentnormamong themanufacturers, andit requireshighervoltages thanever. Therefore,mitigating theadverseeffects isnot likelybyemploying lowchargingvoltages. To avoid these effects, and to provide efficient charging with the available infrastructure, coordinatedcharging(alsocalledcontrolledorsmartcharging)has tobeadopted. In this scheme, the EVsarechargedduringthe timeperiodswhenthedemandis low, forexample,aftermidnight. Such schemesarebeneficial ina lotofways. Itnotonlypreventsadditionofextra loadduringpeakhours, butalso increases the load invalleyareasof the loadcurve, facilitatingproperuseof thepowerplants withbetter efficiency. In [116],Richardsonet al., showed that a controlled charging rate canmake highEVpenetrationpossible in thecurrent residentialpowernetworkwithonlyafewupgrades in the infrastructure.Gengetal.,proposedachargingstrategy in[120]comprisingof twostagesaimed atprovidingsatisfactorychargingforall connectedEVswhileshiftingthe loadsonthe transformers. Ontheconsumerside, it canreduce theelectricitybill as theelectricity is consumedbytheEVsduring offpeakhours,whichgenerallyhaveacheaperunit rate thanpeakhours.Accordingto [121], smart chargingsystemscanreduce the increase investmentcost indistributionsystemby60–70%.Themajor problemsthatare faced in thepowersystemsbecauseofEVscanbechartedas following: • Voltage instability:Normallypowersystemsareoperatedclose to their stability limit. Voltage instabilities in such systemscanoccurbecauseof loadcharacteristics, and that instability can leadtoblackouts. EVloadshavenonlinearcharacteristics,whicharedifferent thanthegeneral industrial ordomestic loads, anddraw largequantitiespower ina short timeperiod [81,122]. Reference[123]corroboratedtothefactthatEVscauseseriousvoltageinstabilityinpowersystems. If theEVshaveconstant impedance loadcharacteristics, then it ispossible for thegrid tosupport a lotofvehicleswithout facinganyinstability [81].However, theEVloadscannotbeassumed beforehand and thus their power consumptions stay unpredictable; addition of a lot of EVs at a time therefore can lead to violation of distribution constraints. To anticipate these loads properly, appropriatemodelingmethodsare required. Reference [124] suggested tackling the instabilitiesbydampingtheoscillationscausedbycharginganddischargingofEVbatteriesusing awideareacontrolmethod. Thesituationcanalsobehandledbychanging the tapsettingsof transformers [125], byaproperlyplannedchargingsystem,andalsobyusingcontrol systems like fuzzy logiccontrollers tocalculatevoltagesandSOCsofbatteries [81]. • Harmonics: The EV charger characteristics, being nonlinear, gives raise high frequency componentsofcurrentandvoltage,knownasharmonics. Theamountofharmonics inasystem canbeexpressedbytheparameters total currentharmonicdistortion(THDi)andtotalvoltage harmonicdistortion(THDv): THDi= √ H ∑ h=2 I2h I1 ×100% (4) THDv= √ H ∑ h=2 V2h V1 ×100% (5) Harmonicsdistort thevoltageandcurrentwaveforms, thuscanreduce thepowerquality. It also causesstress in thepowersystemequipment likecablesandfuses [122]. Thepresentcabling iscapable ofwithstanding25%EVpenetration if slowcharging isused, incaseof rapidcharging, theamount comesdownto15%[126].Voltage imbalanceandharmonicscanalsogiverise tocurrentflowinthe neutralwire [127,128].Differentapproacheshavebeenadoptedtodetermine theeffectsofharmonics duetoEVpenetration. Reference [127] simulatedtheeffectsofharmonicsusingMonteCarloanalysis to determine thepower quality. In [129] the authors showed thatTHDv can reach 11.4% if a few numberofEVsare fast charging. This is alarmingas the safety limit ofTHDv is 8%. According to 52
