Energies 2017,10, 437 3.1. PELoss TheMG1 andMG2 losseswere calculated from the efficiencymap. The efficiency ofMG1 orMG2canbedetermined fromtheoperationpoint for thegiven torqueand speed (Figure 8a,b). Thehigh-voltageDC/DCconverter (HDC)boosts thebatteryvoltage inconsiderationof theoperating conditionsofMG1orMG2.WhentheHDCboosts thebatteryvoltage,aboost lossoccurs. TheHDC losswasdeterminedfromtheHDCefficiencywithrespect tothebatterypower(Figure8c). Inaddition, thebattery losswasobtainedfromthecharge (discharge)efficiency. In thisstudy, thebatterycharge (discharge)efficiencywasassumedtobe98.5%[21]. (a) (b) (c) 0* VSHHG USP 0* VSHHG USP %DWWHU\ SRZHU N: Figure8.Theefficiencymapderivedfromtheexperimental result for: (a)motorgenerator1 (MG1); (b)MG2; (c)high-voltageDC/DCconverter (HDC). 3.2.DrivetrainLoss Thedrivetrain losseshavebeendescribed indetail in the literature [22].Ashort summaryof the drivetrain losses isas follows: Gear loss:Gear losswasassumedtobe1%of the transmittedtorque[23],which iswidelyused in theautomotive industry. Planetarygear loss:Whenthesun,pinion, andringgeararemeshing, theplanetarygear loss occursdueto thegear teeth friction. Theplanetarygear loss is representedas [24,25]: Tloss_PG= ⎧⎪⎪⎨ ⎪⎪⎩ kPG×Tin_PG, whenthecarrier isfixed kPG× ( Zr Zr+Zs ) ×Tin_PG, whentheringgear isfixed kPG× ( Zs Zr+Zs ) ×Tin_PG, whenthesungear isfixed, (4) whereTloss is the torque loss,Tin is the input torque,andk is thecoefficientof frictionforPG. Bearingloss:Thereare loadedandunloadedlosses in thebearing. Loadedloss isproportional to thebearing load. The loadedloss iscalculatedas follows[26,27]: Tloss_BRGload= f1×P1a×dmb×10−3, (5) wherea,b, and f1 are thecoefficientsaccordingto thebearingtype,P1 is theequivalentbearing load andisdeterminedfromtheaxialandradialbearingreactionforce,anddm is thebearingmeandiameter. Bearingunloadedloss iscausedbytheslipbetweentherotatingsurfaceandthe lubricationoil film.Thebearingunloadedloss is representedas Tloss_BRGunload= { 1.6×10−8× f0×dm3, if (υoil×n)< 2000mm2s·min 10−10× f0×(υoil×n) 2 3×dm3, if (υoil×n)≥ 2000mm2s·min , (6) where f0 is thecoefficient for thebearingunloaded loss,υoil is thekinematicviscosity, andn is the bearingrotational speed. 272
