Dataset Type Vertices Runtime Chars4Testing measured 10,492 0.044s cuneusideal synthetic 15,521 0.071s Half4Testing measured 282,428 0.789s HOSG10Preview measured 371,711 1.809s VAT 10908 measured 3,034,899 12.269s HOSG10Full measured 6,596,964 33.319s Table 1: Performanceof the algorithmonmultiple data sets. Dataset name, type, number of vertices and the respective runtimearegiven. Figure 3: Detected ridge points in the realworld data setChars4Testing. It can be seen that the points followthe ridgesof themeshnicely. (a) (b) Figure4: High resolutiondatasetHOSG10Full (a)beforeand (b)after smoothing. 4. OutlookandSummary Futureenhancementsofouralgorithmaretheimplementationofamarchingfront toconnect theridge points to lines,makingthemexportableasSVG.FollowingtheCannyapproach,hysteresis trackingis a futureextensionprovidinganevenmore robust selectionof featurepoints. Furthermore smoothing of the function values instead of smoothing themeshwill improve the performance by reducing the computational overhead of processingM2. The final vision is to have a completely autonomous system, which begins transcribing the ancient tablets immediately after their acquisition, exporting thedigital drawingswithautomatedannotationsdirectly intoa searchabledatabase [6]. The algorithm implemented in this work succeeds in extracting ridge points from irregular grids, using non-maximumsuppression. Although the execution on an irregular surfacemesh architecture 181
